RS752 RP752
  1.  Industrial Rackmount Ethernet Switch

The RS752 is a high-performance managed industrial Ethernet switch equipped with 4 10G SFP uplink ports and 48 10/100/1000Base-X SFP slots, supporting PoE via DC input. Designed with a fanless thermal architecture, wide operating temperature range, and high ingress protection, the RS752 delivers exceptional reliability in harsh environments, including high/low temperature conditions and lightning-prone areas. This switch integrates rich Layer 2 and Layer 3 features, including advanced security functions (ACL, IP Source Guard, Port Security, Dying Gasp), IPv4/IPv6 routing capabilities (ECMP, VRRP, OSPFv2, IS-IS), and supports ERPS (Ethernet Ring Protection Switching) to enhance network resilience and flexibility. With its industrial-grade design and extensive protocol support, the RS752 is ideal for demanding applications such as railway systems, smart cities, intelligent transportation, outdoor surveillance, and other mission-critical deployments.
Related Downloads Inquiry cart

10G High Throughput Ethernet Switching
・52-port Ethernet, including 48-port Gigabit Ethernet and 4-port 1/10GbE dual speed SFP+
・Outstanding throughput and flexibility for high-density and ultra high speed connection
・144Mbps maximum forwarding rate
・336Gps switching capacity
・16K MAC address table
・4K VLAN
・12MBytes packet buffer
・10K Bytes Jumbo Frame
・<10us forwarding delay
・Store-and-Forward with non-blocking Switch Fabric


Management Features
・Auto-Installation for simple plug-and-play deployment
・Various configuration paths, including WebGUI, CLI filtering, Telnet/SSH, SNMP and RMON
・Network administrators can manage the switch through an industry-standard CLI and configure remotely through SNMP from MIB and private MIB, which significantly reduce operating costs
・Port Mirroring: SPAN, RSPAN

Optional PoE
・48 Ports 802.3af/at PoE with PoE management
・DC48-58V Power Input
・300W Total PoE Budget

Enhanced Cyber Security for Critical Applications
・240 ACL entries, IP Standard ACL / ACL6, MAC Extended ACL / ACLv6, IP Extended ACL / ACLv6
・IP Source Guard, DHCP Snooping, DDoS, Port Security
・802.1X/RADIUS

Dynamic Routing with Redundancy Protection
・IPv4 and IPv6 routing: OSPF, OSPFv2 and ECMP
・VRRP guarantees sustainable routing in a single point of failure

Industrial Design for High Reliability
・Wide operation temperature range -25℃~+70℃
・IP40 Protection with fanless design
・Surge Protection of Power and Ethernet Ports
・High EMC/EMI standards
Specifications
 Technology
Standard IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet copper
IEEE 802.3z Gigabit Ethernet Fiber
IEEE 802.3ae 10 Gigabit Ethernet over fiber
IEEE 802.3x Flow Control and back-pressure
  IEEE 802.1p Class of Service (CoS)
IEEE 802.1Q VLAN and GVRP
IEEE 802.1Q Double Tag VLAN (QinQ)
IEEE 802.1D Rapid Spanning Tree Protocol(RSTP)
IEEE 802.1S Multiple Spanning Tree Protocol(MSTP)
IEEE 802.3ad Link Aggregation Control Protocol(LACP)
IEEE 802.1xPort based Network Access Protocol
 Performance
Switch Technology Store and Forward Technology with Non-Blocking Switch Fabric
Number of MAC Address 316K
Packet Buffer Memory  12M Bytes
Jumbo Frame 10K Bytes
VLAN 4K VLANs
VLAN ID 1~4093
Class of Service 8 Priority Queues per Port
 Interface
Ethernet Port 48 x 10/100/1000Base-T RJ45, Auto Negotiation
4 x 1/10G SFP+, Auto Negotiation/DDM
System LED 1 x Power: Green On
1 x System Status: Ready (Green On), Failure (Amber On)
Ethernet Port LED Link (Green On), Activity (Green Blinking), Speed 1000M(Amber On), Speed 100M (Green On) , Speed 10M (Off)
SFP LED Link (Green On), Activity (Green Blinking)
Console 1 x RS232 for System Configuration. Baud Rate: 115200.n.8.1
 Power Requirement
Input Voltage Non-PoE：DC12-58V；AC100~240V 50-60HZ
PoE：DC48-58V
Power Consumption Non-PoE<35W
PoE<400W
 Software
Management  Interface Console: Command Line Interface (CLI)
Management Port: Telnet, SNMP, CGI WebGUI
Time Management Network Time Protocol NTP
Network Management IPv4/IPv6, SNMP v1/v2c/v3/Trap, MIBs, RMON, TFTP, System Log, SMTP, Management IP
Traffic Management Flow Control, 64 Link Aggregation, VLAN, QinQ, Class of Service, Traffic Prioritize, IGMP Snooping v1/v2/v3, Rate Control, Port Mirror SPAN, RSPAN
L3 Routing IPv4/IPv6 routing, RIP, OSFP v2, ECMP, VRRP, IGMPv1/v2/v3
Security IEEE 802.1X/RADIUS, SSH, SSL, ACL L2/L3/L4, IPv6 ACL L3/L4, IP Source Guard, DHCP Snooping
Redundancy Rapid Spanning Tree Protocol (RSTP), Multiple Spanning Tree Protocol (MSTP), ERPS
 Mechanical
Installation 19”, 1U Rackmount
Enclosure Material Steel Metal IP40
Dimension 440 x 44 x 245 mm (W x H x D)
Weight 3.6kg with package
 Environmental
Operating Temperature & Humidity -25°C~70°C , 10%~95% Non- Condensing
Storage Temperature -40°C~85°C
MTBF 100,000 hours
Warranty 3 years
 Standard
Surge protection of Power      AC: IEC 61000-4-5  Level 3（4KV/2KV）（1.2/50us）
DC: IEC 61000-4-5  Level X（8KV/8KV）（1.2/50us）
Surge protection of Ethernet ports  IEC 61000-4-5  Level 3（4KV/2KV）（10/700us）
Radiated Immunity Test IEC 61000-4-3  Level 3 （10V/m）
Electrical Fast Transient / Burst Immunity Test  IEC 61000-4-4  Level 3 （1V/2V）
conducted immunity IEC 61000-4-6  Level 3 （10V/m）
Power Frequency Magnetic Field Immunity IEC 61000-4-8  Level4（30A/m）
Voltage Dips IEC 61000-4-11  Level3 （10V）
ESD protection IEC 61000-4-2  Level 4 （8K/15K）

​
Ordering Information
 Model Name
RS752-AC-E Industrial 48G+4 10G SFP+ Gigabit Routing Switch, AC Power, EU plug
RS752-AC+DC-E Industrial 48G+4 10G SFP+ Gigabit Routing Switch, AC+DC Power, EU plug
RP752-48GP-2DC Industrial 48G+4 10G SFP+ Gigabit Routing PoE Switch, 48xPoE, dual DC 48-58V
Package List
1 x Product Unit (Without SFP transceiver)
2 x Rackmount Ears
1 x RS232 Console Cable
2 x Power Cord
1 x Quick Installation Guide

Optional Accessory
 Item
SFPXGM03 SFP+, 10Gbps, LC, multi, DDM, 300Meter, 0~70℃
SFPXGM03T SFP+, 10Gbps, LC, multi, DDM, 300Meter, -40~85℃
SFPXGS10 SFP+, 10Gbps, LC, single, DDM, 10KM, 0~70℃
SFPXGS10T SFP+, 10Gbps, LC, single, DDM, 10KM, -40~85℃
